1/4 in. Brass Ball Valve, Male x Female | 948170
1/4 in. Brass Ball Valve, Male x Female | 948170
Backordered at the manufacturer — available to order; shipping date is not currently confirmed.
Flat-rate shipping, nationwide- Orders under $100: $9.95
- $100 – $499.99: $14.95
- Orders $500+: quoted — real freight for your order, not a flat guess
Volume order or crossing a competitor part number? Request a quote — usually answered the same business day.
The 1/4 in. forged brass full-port ball valve (part 948170) delivers quarter-turn shutoff with Male × Female NPT ends — the male end threads directly into equipment ports, tanks, or bushings while the female end accepts standard pipe, eliminating an extra nipple. Manufacturer-designated UL 842 / UL 258 (listing file not independently verified by Apex), rated 600 psi WOG non-shock and 150 psi WSP saturated steam, with a solid hard-chrome-plated brass ball and virgin TFE seats. Each valve individually tested.
Technical Specifications
| Manufacturer Part Number (MPN) | 948170 |
| Nominal Size | 1/4 in. |
| Valve Type | Full-port ball valve, forged brass |
| End Connections | Male NPT × Female NPT, ANSI B1.20.1 |
| Pressure Rating | 600 psi WOG non-shock (42 bar) |
| Steam Rating | 150 psi WSP saturated steam (10.34 bar) |
| Temperature Range | −20°F to 248°F (−40°C to 120°C) |
| Listings | UL 842, UL 258 — manufacturer designation; listing file not independently verified by Apex |
| Port | Full port (full bore) |
| Operation | Quarter-turn lever, yellow vinyl-insulated handle; flow both directions |
Dimensions
| Bore Diameter | 0.315" |
| End-to-End Length | 2.016" |
| Height (center to top) | 1.689" |
| Handle Length | 2.756" |
| Weight | 0.29 lb |
Materials of Construction
| Body | Forged Brass (C37700) |
| End Cap | Brass |
| Ball | Brass, hard chromium plated |
| Stem | Brass, bottom-entry, blow-out-proof, pressure-retaining |
| Seats, Stem Packing & Thrust Washer | Virgin TFE |
| Handle | Heavy-duty plated carbon steel, yellow vinyl insulator |
Performance & Testing
- Full-port bore — minimal pressure drop
- Each valve individually pressure tested
- Confirm media and service compatibility with the manufacturer before specifying
- Fast 1/4-turn open/close, low operating torque, bidirectional flow
- Adjustable stem packing gland — field-serviceable seal
- Not lead-free — for potable water supply lines, choose a lead-free certified valve (see Lead-Free Valves in our Valves menu)
Other Sizes in This Series
Brass Ball Valve, Male × Female NPT, manufacturer-designated UL 842 / UL 258, 600 WOG Full Port (1/4"–2"). Jump to another size:
| Size | Part # |
| 1/4 in. (this page) | 948170 |
| 3/8 in. | 948171 |
| 1/2 in. | 948172 |
| 3/4 in. | 948173 |
| 1 in. | 948174 |
| 1-1/4 in. | 948175 |
| 1-1/2 in. | 948176 |
| 2 in. | 948177 |
Typical Applications
Gas, water and oil distribution lines (manufacturer-designated UL 842 / UL 258), street-valve style installs where the male end threads into a fitting or tank bushing, fuel transfer, compressed air, and general industrial shutoff. Not for potable water supply (not lead-free).
Cross-References & Interchange
Replacing another brand's 1/4 in. manufacturer-designated UL 842 / UL 258 MxF brass ball valve? Match nominal size, end connections (Male × Female NPT), and WOG rating for a direct fit — or send us your part number and we will confirm the interchange. Need a padlockable handle? See the 1/4 in. MxF locking-handle ball valve (948170L). Need female threads on both ends? See the 1/4 in. 600 WOG full-port ball valve (940171).
