1/2 in. x 1/4 in. Push-In x Male NPT Elbow
Sizes in This Series
Forged brass 90-degree push-in x Male NPT elbows. Jump to another size or add it straight to your cart:
| Size | Part # | Price | Cart |
| 1/4 in. x 1/4 in. | 20069 | $4.84 | Add to cart |
| 3/8 in. x 1/4 in. | 20072 | $6.99 | Add to cart |
| 1/2 in. x 1/4 in. (this page) | 20074 | $10.99 | — |
Overview
The Midland 20074 is a forged brass 90-degree elbow joining 1/2 in. push-in tubing to a 1/4 in. Male NPT port. The push-to-connect collet seals the larger tube on insertion, and the right-angle body routes higher-flow air or fluid around tight corners.
Technical Specifications
| MPN | 20074 |
| Tube Size (Push-In) | 1/2 in. |
| Thread Size | 1/4 in. - 18 Male NPT |
| Connection Type | Push-to-Connect x Male NPT, 90° |
| Temperature Rating | -10°F to 200°F |
Materials of Construction
| Body | Forged Brass |
| Collet / Grip Ring | Acetal with stainless gripping teeth |
| O-Ring Seal | Nitrile (NBR) |
Typical Applications
Used where a 1/2 in. tube must turn 90 degrees into a 1/4 in. NPT port for higher-flow pneumatic and fluid runs on machinery, manifolds, and equipment frames. The forged brass body handles vibration and repeated reconnection.
Cross-Reference and Interchange
This push-in elbow cross-references to these competitor and industry part numbers: 02069-0804, 269PP-8B, 69PC-8-4, PC69-8B, QPL69-8-4, W169PLNS-8-4. Replacing one of these? Match nominal size, connections, and rating, or send us your part number and we will confirm the interchange.
Sizing and Installation Resources
- Push-to-Connect Fittings Selection Guide
- NPT Thread Tightening: Turns Past Hand-Tight
- Pipe Size Reference Chart
- Teflon Tape vs. Pipe Dope
Frequently Asked Questions
What tubing fits the push-in end?
1/2 in. (12 mm nominal) OD tubing inserts directly into the collet.
Does the elbow swivel?
No. This is a fixed 90-degree elbow. For a rotating leg, choose a swivel elbow.
How do I seal the NPT thread?
Apply PTFE tape or pipe dope and tighten one to two turns past hand-tight.
What is the temperature range?
Rated for -10°F to 200°F service.
